Call for prices

System Interface USB2.0
Scan Pattern Single line
Light Source Visible Laser Diode 650nm±10nm
Visual Indicators Green=laser shines, ready to scan / red= successfully decoding
Scan Speed 72scans/second
Depth of field 9”**
Resolution 4mil
Scan Angle Horizontal : 46° maximum
Pitch, Skew 68°, 52°maximum
Decode Capabilities Codabar, Code 3 of 9 including PARAF, Interleaved 2 of 5, Straight 2 of 5 Industrial, Matrix 2 of 5, Code 11, Code 93, Code 128, UPC, EAN/JAN, China Postal Code, GS1 DataBar. 2005 Sunrise/GTIN compliant
Input Voltage 5VDC ±0.25V
Agency Approvals class A, BSMI
Laser Level Class 1; IEC60825-1, EN60825-1
Environment Operation Temperature: 0°C to 40°C
Storage Temperature: -40°C to 60°C
Humidity 5% to 95% relative humidity, non-condensing
Light Levels 4842LUX(450m candlelight)
Drop Designed to withstand 1m drops
Environmental Sealing Sealed to resist airborne particulate contaminants
Dimension Length 110mm
Height 153mm
Width 70mm
Weight 120g
Note * Specifications are subject to change without notice. All company and/or product names are trademarks and/or registered trademarks of their respective owners
